Wood Chipper
Drum Wood Chipper
Material : Log, twigs, bark, sugarcane stalk, bamboo,etc.
Size : 20-35 mm
Capacity : 3-35 t/h
Power : 45-220 kw
Appliaction : For turning wood waste into wood chips for further processing
SEND INQUIRY
Wood Chipper Introduction
Wood Chipper is special for processing large –size wood waste like log, twigs, bamboo, etc. into quality wood chips for further processing. Therefore, it is a widely-used auxiliary equipment in wood pellet production followed by hammer mill. It is also a popular choice in particleboard mill, fiberboard factory, biomass power plant, paper mill,etc.
Yearmega drum wood chipper is well known for simple operation and durable quality. The final product is of uniform size and high quality. A high cost-effective machine for you.
Main Features of Wood Chipper
1. Large capacity of 3-35 t/h for you too choose from.
2. A variety of raw material are available including wood material and non-wood material.
3. Adjustable wood chip size according to your need.
4. High strength and high precision box, carbide blades and imported bearing.
5. It is adopted with hydraulic feeding mechanism.
What Materials Can Be Chipped
▷ Wood Mateial: logs, undersized logs, timber residues(tree branches, twigs, etc), wood processing residues(lath, skins, core logs, veneer waste,etc.)
▷ Non-wood fiber: sugarcane stalk, bulrush, bamboo, cotton stalk, reed, straw,etc.
Customers’reflection of Wood Chipper
Technical Data of Wood Chipper
Type | GXP-215 | GXP-216 | GXP-218 | GX-2110 | GXP-2113 |
Output capacity (t/h) |
3-5 | 8-12 | 10-20 | 15-25 | 25-35 |
Wood chips length (mm) |
20-35 | 20-35 | 20-35 | 20-35 | 20-35 |
Knife qty (pcs) |
2 or 3 | 2 or 3 | 3,4 ,5 | 3,4 ,5 | 3,4,5 |
Main motor power(kw) |
45 | 55 | 110 | 132-160 | 220 |
Feeding motor power(kw) |
2.2-3 | 3-4 | 4-5 | 7.5-11 | 11 |
Diameter of roller(mm) |
500 | 600 | 800 | 1000 | 1300 |
Feeding port size(cm) |
16*40 | 23*50 | 30*68 | 50*100 | 50*70 |
Rotary speed of roller (rpm) |
590 | 590 | 650 | 500 | 500 |
Feeding speed (m/minute) |
38 | 38 | 38 | 38 | 38 |
Maxi diameter of logs(mm) |
160 | 200 | 300 | 420 | 450 |
Feeding conveyor length(m) |
6 | 6 | 8 | 8 | 8 |
Feeding conveyor power(kw) |
2.2 | 4 | 4 | 11 | 11 |
Discharge conveyor length(m) |
10/12 | 10/12 | 10/12 | 10/12 | 10/12 |
Discharge conveyor length(kw) |
2.2 | 3 | 5.5 | 5.5 | 7.5 |
Weight(kg) | 2990 | 4070 | 7200 | 12500 | 14500 |
Size (l*w:h) (mm) |
1540 1240 1020 |
1980 1950 1250 |
2300 2150 1500 |
3850 2448 2050 |
3850 2448 2050 |
